8 Ton Mini Excavators Tilting Dual Lock Pin Grabber
Cat® Tilting Dual Lock Pin Grabber Couplers – Mini Excavator allow work tools to be changed quickly – improving overall production and increasing machine versatility. The Tilting Dual Lock Coupler maintains a tight fit with an innovative wedge design throughout the life of the coupler. It can be used with compatible pin-on work tools and in front shovel mode with buckets. The Tilting Dual Lock Coupler also comes with a visible locking mechanism for added security.
Weight
203.3 kg
Overall Width
370 mm
Length
622 mm
Overall Height
601 mm
Drive Method
Helical Rotary Actuator
Hydraulic Flow
19-26.5 lpm (5-7 gpm)
Hydraulic Pressure - Actuator
207 bar
Hydraulic Pressure - Coupler
320 bar
Pin Diameter
50 mm
Machine Class
8 Ton Mini Excavators
Interface Type
Pin On
Required Hydraulics
Dedicated Factory Installed
Tilt Angle Range +/-
180 degrees
